Videx 4902/S keypad module
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx 4902/S is a keypad module from the 4000 Series range.
Introducing the Videx 4902/S 4000 Series 1000-Codelock Keypad Module, crafted from sleek mirror stainless steel for a modern touch. This keypad module is designed for durability and ease of use, making it an ideal choice for secure access control. With its advanced coding system, you can effortlessly manage entry permissions, ensuring safety and convenience.
Perfect for both residential and commercial applications, this keypad module combines functionality with style. Don't wait, enhance your security now!
Key features
- 2-Dry contact relay outputs, normally open and normally closed (24VAC/DC, 5A max)
- 1000 Programmable 8 digit access codes; each code can be set to activate relay 1, relay 2 or both
- Each relay can be set to activate for a specific time (1 to 255 seconds) or to work in a latch mode
- 2-Active low inputs to trigger relay 1 and 2 (Push to exit inputs)
- Keypad programming menu protected by a 4-8 digit programmable secret code
- Visual and acoustic signalling during operation and programming
- Keypad illumination LEDs
- PC Programming facility (using specific software and RS-485 or USB cable)
- 2-Operating modes; Standard as standalone codelock or VNET LITE network with RS485 bus, Network as serial codelock unit connected via RS-485 to a remote control unit Art. 1050 or Art. 1052
If you are matching this to an existing installation, work from the 4902/S part number rather than the description.
Specifications
Product information
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | 4902/S |
| Product Series | 4000 Series |
| Product Type | Codelock Module |
Product information
| Finishing | Mirror Stainless Steel Finish |
|---|
Videx 4902/S keypad module
