Winland Electronics EA400-24 environment monitoring device
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Winland Electronics EA400-24 is an environment monitoring device from the EnviroAlert 400 range.
The EnviroAlert EA400 critical-environment monitoring device provides visibility of up to 4 environmental factors including temperature, humidity and water detection. When a condition deviates from the predetermined threshold both visual and audible (Piezo buzzer required 3rd party buzzer add on) notifications occur. When integrated into a security panel, the system allows for the real-time notification of an incident and immediate corrective action.
Key features
- Simultaneous operation of four external sensors (sold separately)
- No on-board sensor
- 8 event incident memory, including time and date
- Monitor for temperature, humidity, or water presence with external sensors
- Easy to read LCD display flashes under alarm condition
- User-friendly configuration set up with tamper proof lock
- Four zone-specific relays, plus one auxiliary relay
- Auxiliary alarm silence feature with 10-minute timer
- Alarm time delay up to 120 minutes to avoid nuisance alarms
- Temperature and humidity high/low set points
If you are matching this to an existing installation, work from the EA400-24 part number rather than the description.
Specifications
Technical information
Physical characteristics
Power description
Attributes
Specifications
| Brand Name | Winland Electronics |
|---|---|
| Manufacturer Part Number | EA400-24 |
| Product Series | EnviroAlert 400 |
| Product Type | Temperature Sensor |
Technical information
| Connectivity Technology | Wired |
|---|
Physical characteristics
| Colour | White |
|---|---|
| Depth | 31.75mm |
| Form Factor | 2-Gang, Wall Mount |
| Height | 120.60mm |
| Width | 152.40mm |
Power description
| Input Voltage | 23-26V DC |
|---|
Attributes
| Environmental status | Yes |
|---|---|
| Input Voltage | 23-26V DC |
