Altron ACC3PMLA Tilt-down Square Section Camera Column, 7.5m, Post Mounted
About this product
The Altron ACC3PMLA is a 7.5 m tilt-down, post mounted square section camera column with flush door lockable access, from the Altron ACC range of square section columns. It provides a stable mounting platform for all camera types, and as a tilt-down model it lets cameras be maintained at ground level.
Key features
- 7.5 m column height
- Max equipment weight at top: 25 kg
- Max equipment surface area: 0.2 m2
- Tilt-down design for camera maintenance at ground level
- Flush door with lockable access; tilt-down models have an internal padlock facility
- Demountable winch, part number DW1500/AC
- High tensile steel, hot dip galvanised after fabrication
- Modular construction for ease of assembly and installation on site
Frequently asked questions
How tall is the Altron ACC3PMLA column?
The ACC3PMLA has a standard height of 7.5 m.
How much camera equipment can the ACC3PMLA carry?
The max equipment weight at top is 25 kg, with a max equipment surface area of 0.2 m2.
How are cameras on the ACC3PMLA maintained?
It is a tilt-down model, so cameras can be maintained at ground level. Allow a column rear clearance of 2000 mm when tilting.
Which winch does the ACC3PMLA use?
The winch part number listed for the ACC3PMLA is DW1500/AC. Tilt-down models use demountable winches.
Can the ACC3PMLA be secured against tampering?
It has flush door lockable access, and tilt-down models have an internal padlock facility.
What is the ACC3PMLA made from?
It is constructed in high tensile steel and hot dip galvanised after fabrication, to ISO 1461.
Specifications
Specifications
| Brand | Altron |
|---|---|
| Model | ACC3PMLA |
| Manufacturer Part Number (MPN) | ACC3PMLA |
| Height | 7.5 m |
| Post type | PMLA (tilt-down, post mounted, flush door lockable access) |
| Max equip weight at top | 25 kg |
| Max equip surface area | 0.2 m2 |
| Post size A2 | 150 mm |
| Lower section B2 | 120 mm |
| Upper section C2 | 90 mm |
| Extension length D | 3 m |
| Door aperture size (HxW) | 280x110 mm |
| Column rear clearance when tilting | 2000 mm |
| Winch part number | DW1500/AC |
| Product weight | 189 kg |
| Construction | High tensile steel, hot dip galvanised after fabrication |
| Galvanising | Hot dipped galvanising after fabrication to ISO 1461 |
| Design | Design analysis in accordance with ILE TR7, BS6399 and BS8100 |
