B-Tech BT8229/B screen wall mount, Black

What it is

The BT8229/B is B-Tech's double arm flat screen wall mount with UltraGlide Tilt & Swivel, in black. UltraGlide Tilt lets users reposition displays up to 35kg with a simple touch, securely holding the tilt in place, and the mount has three swivel points, at the wall, arm and interface.

It is compatible with 16" stud walls, brick and concrete surfaces, and is engineered for both commercial and home installations.

Adjustment and fit

The recommended screen size is up to 65" with a max load of 35kg, and universal fixings go up to 600 x 400mm. Swivel is 180˚ at the wall and interface and 360˚ at the central pivot.

Screen levelling is toolless (+ / -3˚) and the screen can be adjusted laterally after mounting (+ / -20mm). The distance from the wall is min 65mm and max 591mm; the slim-line design allows close-to-wall installation when folded flat.

Installation

Installation is a simple 'hook-on' installation with all mounting hardware included, and a printed template for wall drilling. Cable management is integrated throughout the mount, safety screws prevent unauthorised screen removal and cover plates are included. The packaging is 100% plastic free.

Ordering: colour black, order ref BT8229/B, EAN 5019318309113.

Buying this in the UK

This item is non-returnable, excluding faulty goods.

We do not quote a warranty term for this part.

Ask us and we will check it for you. Your statutory rights are unaffected.
