C-TEC QT688/2 security alarm, Flush Mount, Junction Box Mount
About this product
C-TEC QT688/2 is a security alarm.
The QT688/2 is a high-output programmable sounder designed for use with the Quantec addressable call system. It can be programmed to suit a specific application using our separately available QT423 Configurator and a compatible PC running the Configurator software.
Key features
- A programmable hi-output addressable sounder operating at up to 85dB(A).
- Designed to increase call indication levels in large Quantec sites.
- Can be configured to sound when certain groups of call points are calling.
- Can be assigned one of 16 different tones (four of which are HTM2015 compliant) for each of Quantec's call states using a QT423 configurator.
- Default operation utilises Quantec's standard tones.
- Adjustable day/night volume controls.
- Connections for an optional slave overdoor light.
- Mounts on a standard UK 25mm single gang flush or surface back box.
If you are matching this to an existing installation, work from the QT688/2 part number rather than the description.
-
Download
- QT688/2 — Product Manual
Specifications
Certifications
Physical characteristics
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | C-TEC |
|---|---|
| Manufacturer Part Number | QT688/2 |
| Product Type | Security Alarm |
Certifications
| RoHS compliance | Compliant |
|---|---|
| WEEE compliance | Compliant |
Physical characteristics
| Depth | 43.00mm |
|---|---|
| Height | 86.00mm |
| Material | Plastic |
| Weight | 80.00g |
| Width | 86.00mm |
Product information
| Mount Type | Flush Mount, Junction Box Mount |
|---|
Miscellaneous
| Environmental certification | CE |
|---|
Attributes
| Environmental status | Yes |
|---|---|
| Weight | 80.00g |
