C-TEC IS-SB-02-02 sounder strobe, Red
About this product
Please note: this is a non-returnable item (excluding faulty goods)
C-TEC IS-SB-02-02 is a sounder strobe.
The C-Tec Moflash EX Intrinsically Safe Sounder Beacon with Red Lens IS-SB-02-02 is expertly designed for use in potentially explosive atmospheres, making it ideal for both Group I Mining and Group II Above Ground applications with a robust IP66 rating, this beacon ensures reliable performance in fire, security, process control, and general signaling applications. It features a user-friendly DIP switch that allows you to choose between a 1 Hz flash rate or a static signal, and its innovative time saver base simplifies installation by connecting during initial wiring. Ensure safety and efficiency with this dustproof and weatherproof beacon, compatible with approved Zener Barriers or Galvanic Isolators.
Key features
- A red intrinsically safe surface mounting 105dB(A) sounder beacon with a red lens
- Designed for use in potentially explosive atmospheres
- Two stage sounder/beacon alarm option and 32 dip-switch selectable alarm tones
- IP66 rated
- Supplied in a flame retardant polycarbonate housing
- 33mA Alarm current
- Conforms to EN 60079-0-2012 All-2013 (IEC 60079-0-2011), EN-60079-11-2012 (IEC 60079-11-2011)
- Must be used in conjunction with an approved Zener Barrier or Galvanic Isolator
- Beacons with different coloured lenses also available – order IS-SB-02-01 for amber, IS-SB-02-03 for blue, IS-SB-02-04 for green or IS-SB-02-05 for white
If you are matching this to an existing installation, work from the IS-SB-02-02 part number rather than the description.
Specifications
Certifications
Physical characteristics
Miscellaneous
Specifications
| Brand Name | C-TEC |
|---|---|
| Manufacturer Part Number | IS-SB-02-02 |
Certifications
| RoHS compliance | Compliant |
|---|---|
| WEEE compliance | Compliant |
Physical characteristics
| Colour | Red |
|---|---|
| Durability | Dustproof, Weatherproof |
Miscellaneous
| Indoor or outdoor use | Outdoor |
|---|
